GeForce RTX 4070 Ti Specs Walkthrough

In the past few years, the gaming industry has shown tremendous success and has become very popular in a very short span of time. The emergence of the internet has made the accessibility of video games very easy. Therefore, people now love to play online games to kill time. That’s why the demand for gaming laptops is also increased. The global gaming market is expanding at a steady pace because of the rise of gamers all across the world. So, the demand for a gaming laptops is also increasing in UAE as well. Different gaming laptops are available at different prices. The RTX 3080 is available at a base price of $699.The RTX 4090 in Dubai is selling at a price of $1599. The RTX 4080 in UAE is available in the range of $899 to $1199. In this article, we are going to discuss the features and specifications of the GeForce RTX 4070 Ti.

GeForce RTX4070 Ti is a graphics card launched on 3rd January 2023 with a launch price of $799. This graphics card delivers a magnificent performance for video gaming and has shown a better result than GeForce RTX 3080 and RTX 4070. Playing 4k games on GeForce RTX 4070 Ti is joyous and entertaining. GeForce RTX 4070 Ti is a successor of the GeForce 30 and belongs to the generation GeForce 40. This graphic card is based on AD104 graphics processor, which is an average-sized chip. GeForce RTX 4070 Ti supports DirectX 12 Ultimate, which makes sure that this card has the ability to run all new video games very smoothly without any obstructions. The suggested power supply for it is 600W.



Comprehensive Specs Walkthrough

Now let’s have a detailed walkthrough of the features and specifications of the GeForce RTX 4070 Ti.

Graphics Processor

GeForce RTX 4070 Ti is based on AD104 GPU and is AD104-400-A1 GPU variant. AD104 GPU is based on Ada Lovelace architecture. It is made using a 4 nm production process with a die area of 295 mm² and has 35,800 transistors embedded in it.

Board Design

GeForce RTX 4070 Ti, having board number PG141 SKU 331, is a dual-slot card and receives power from 1x 16-pin power connector with a maximum power draw of 285 W. The dimensions of RTX 4070 Ti are 285 mm x 112 mm x 42 mm. For displaying outputs, RTX 4070 Ti has 1x HDMI 2.1 and 3x Display Port 1.4a. RTX 4070 Ti has PCIe 4.0 x16 bus interfaces. PCIe 4.0 x16 means a Gen 4 expansion card or 16-lane configuration slot.

Clock Speeds

The GPU (Graphics processing unit) is running at a frequency of 2310 MHz, which can be amplified up to 2610 MHz. The GPU has memory running at 1313 MHz (21 Gbps effective).

Memory

 GeForce RTX 4070 Ti has 192- bit memory interface, which is used to connect 12 GB GDDR6X memory and a bandwidth of 504.2 GB/s.

Render Configuration

In addition, the Direct X 12 ultimate has the capability to ensure the support of hardware-ray tracing. It has 60 ray-tracing acceleration cores, 7680 shading units, and 240 texture mapping units. It also attributes 240 tensor cores which are used to upgrade the speed of machine learning applications. It has 80 ROPs or raster operations pipeline that is used in the rendering process of the modern graphics card. It has 60 SM counts and 60 RT cores that are allocated for performing the ray-tracing operation with exceptional efficiency. It has L1 cache of 128 KB (per SM) and L2 cache of 48 MB, which can be accessed very quickly.

Theoretical Performance

GeForce RTX 4070 Ti has a pixel rate of 208.8 GPixel/s, which means it can render 208 pixels per second on the screen. RTX 4070 Ti has a texture rate of 626.4 GTexel/s.

GeForce RTX 4070 Ti has FP16 (half) performance of 40.09 TFLOPS (1:1), FP32 (float) performance of 40.09 TFLOPS, and FP64 (double) performance of 626.4 GFLOPS (1:64).

Graphics Features

GeForce RTX 4070 Ti also uses DirectX 12 Ultimate (12_2). It also uses ray tracing and variable rate shading to make games more realistic. RTX 4070 Ti uses OpenGL 4.6 to draw vector graphics and make animations more responsive. OpenCL version 3.0 is used in this GPU. Vulkan version 1.3 is used for high-efficiency, cross-platform access to GPUs. GeForce RTX 4070 Ti uses CUDA 8.5 to allow the software to use different types of graphics processing units for GPUs. It uses shader model 6.7.

Ending Note

GeForce RTX 4070 Ti is a graphic card that ensures entertaining gameplay. It has a peak performance for both 1440p and 4k game monitors. It is an enthusiast-class graphic card that ensures that all modern online games will run on it very smoothly. It is 20 percent faster than RTX 3080 with just an increase of 15 percent in price.
