MSI MPG X870-E Carbon Wifi Motherboard in Qatar

Struggling to find a motherboard with high overclocking capabilities?

Without the right motherboard, you miss out on extreme performance potential, especially for gaming and demanding tasks.

The MSI MPG X870-E Carbon Wifi Motherboard in Qatar supports AMD Ryzen™ 9000/8000/7000 processors and offers DDR5 memory overclocking up to 8400+ MT/s. With PCIe 5.0 support, Wi-Fi 7, and USB4 ports, this motherboard ensures superior connectivity, speed, and stability for all your performance needs.

MSI MPG X870-E Carbon

Wifi Motherboard Features in Qatar

Discover the cutting-edge features of MSI MPG X870-E Carbon Wifi, designed for overclocking, connectivity, and elite gaming setups.

• Supports AMD Ryzen™ 9000/8000/7000 Series processors
• 4x DDR5 slots with maximum memory capacity of 256GB
• PCIe 5.0 for faster data transfer speeds
• 4x M.2 slots, including PCIe 5.0 x4 support
• Wi-Fi 7 and Bluetooth 5.4 for advanced wireless connectivity
• Realtek® ALC4080 Codec with 7.1-Channel high-performance audio
• Supports overclocking with AMD EXPO™ technology
• Comprehensive connectivity with multiple USB Type-A and Type-C ports

Upgrade your gaming experience with MSI MPG X870-E Carbon Wifi today!

Finding a high-performance motherboard for cutting-edge gaming is tough.

Many motherboards fail to keep up with the latest processors, memory speeds, and connectivity, limiting your gaming experience.

MSI MPG X870-E Carbon Wifi in Qatar solves this by supporting AMD Ryzen™ 9000 Series processors, DDR5 8400+ MT/s memory, PCIe 5.0 for blazing-fast data transfer, and Wi-Fi 7 for ultra-low latency. With extensive storage support and robust connectivity, this motherboard powers elite gaming setups with ease.

MSI MPG X870-E Carbon

Wifi Motherboard Specs

Get in-depth technical specifications of the MSI MPG X870-E Carbon Wifi, supporting AMD Ryzen processors, PCIe 5.0, DDR5, and more.

Chipset	AMD X870E
CPU	Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors Socket AM5
Memory	4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support DDR5 8400+(OC)/ 8200+(OC)/ 8000+(OC)/ 7800(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MT/s Ryzen™ 9000 Series Processors max. overclocking frequency: • 1DPC 1R Max speed up to 8400+ MT/s • 1DPC 2R Max speed up to 6400+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 4800+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPOTM Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only* * CUDIMM support and POR boot frequency may vary by CPU series, with manual overclocking available after boot. Certain CPUs may fail to boot, but future BIOS updates will improve compatibility. • The DIMM slots on this motherboard have double-sided latches. • Memory compatibility and supported speeds can vary depending on the CPU and memory configuration. For detailed information, please refer to the Memory Compatibility List available on the product’s Support page or visit https://www.msi.com/support/.
Onboard Graphics	1x HDMI™ Support HDMITM 2.1 with FRL port, maximum resolution of 8K 60Hz* 2x Type-C DisplayPort USB4® port, supporting DisplayPort 1.4 with HBR3 over USB Type-C, maximum resolution of 4K@60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
Slot	3x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 5.0 supports up to x4 (From CPU) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E1 & PCI_E2 slots • Supports PCIe 5.0 x16/x0 or x8/x4 (For Ryzen™ 9000/ 7000 Series processors) • Supports PCIe 4.0 x8/x0 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports PCIe 4.0 x4/x0 (For Ryzen™ 8500/ 8300 Series processor) PCI_E3 slot • Supports up to PCIe 4.0 x4 * PCI_E1 & PCI_E2 & M.2_2 share the bandwidth, and PCIe version support varies depending on the CPU. Please refer to the PCIe configuration table in the manual for more details.
Audio	Realtek® ALC4080 Codec 7.1-Channel USB High-Performance Audio Supports up to 32-Bit/384 kHz playback on front panel Supports S/PDIF output
Storage	4x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280 devices M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G M.2_1 slot • Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors) • Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors) M.2_2 slot* • Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors) • The M2_2 slot will be unavailable when using Ryzen™ 8000 Series processors * PCI_E1 & PCI_E2 & M.2_2 share the bandwidth, and PCIe version support varies depending on the CPU. Please refer to the PCIe configuration table in the manual for more details.
RAID	•Supports RAID 0, RAID 1 and Raid 10 for SATA storage devices •Supports RAID 0, RAID 1 and Raid 10* for M.2 NVMe storage devices * RAID 10 for M.2 NVMe storage devices is only supported by AMD Ryzen™ 9000/7000 series CPU.
USB	4x USB 2.0 (Front) 4x USB 5Gbps Type A (Front) 9x USB 10Gbps Type A (Rear) 2x USB 10Gbps Type C (Rear) 1x USB 20Gbps Type C (Front) 2x USB 40Gbps Type C (Rear)
LAN	1x Realtek® 8126 5G LAN 1x Realtek® 8125 2.5G LAN
Internal IO	1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 5x System Fan 1x EZ Conn-header (JAF_2) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Thermal Sensor connectors(T_SEN) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 20Gbps Type C ports
WIRELESS LAN & BLUETOOTH	Wi-Fi 7 Solution The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth® 5.4**, MLO, 4KQAM * 6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2. ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2.
LED FEATURE	4x EZ Debug LED 1x EZ Digit Debug LED
BACK PANEL PORTS	USB 10Gbps Type-A Flash BIOS Button Clear CMOS Button Smart Button 2.5G LAN 5G LAN Audio Connectors HDMI™ USB 40Gbps Type-C USB 10Gbps Type-C USB 10Gbps Type-A USB 10Gbps Type-C Wi-Fi / Bluetooth Optical S/PDIF Out
OPERATING SYSTEM	Support for Windows® 11 64-bit
BOX CONTENT	European Union Regulatory Notice Quick Installation Guide Cable Sticker Shout out flyer EZ Wi-Fi Antenna EZ M.2 Clip II EZ M.2 Clip II Remover 1 to 3 EZ Conn-Cable (V2) USB Drive 2 x SATA Cables ARGB Extension Cable 1 to 2 RGB Extension Cable EZ Front panel cable
PCB Info	ATX 243.84mmx304.8mm

FAQ

Frequently Asked Questions about MSI MPG X870-E Carbon Wifi Motherboard.

What processors are supported by the MSI MPG X870-E Carbon Wifi?

It supports AMD Ryzen™ 9000/8000/7000 Series desktop processors with socket AM5.

What is the maximum memory capacity?

The motherboard supports up to 256GB of DDR5 memory across 4 DIMM slots.

Does this motherboard support overclocking?

Yes, it supports memory overclocking up to DDR5 8400+ MT/s and AMD EXPO™ technology.

What wireless features are included?

It comes with Wi-Fi 7 and Bluetooth 5.4 for high-speed wireless connectivity.

How many M.2 slots does the motherboard have?

It has 4 M.2 slots, with PCIe 5.0 support on M.2_1 and M.2_2 slots.
