Micro Converter HDMI to SDI 12G is a miniaturized broadcast-quality converter designed to connect HDMI cameras and computers to professional SDI equipment. Available in Qatar, it provides two 12G-SDI outputs that automatically match the HDMI input and support Level A or Level B selection for 3G-SDI signals. Full-size HDMI and professional SDI connections provide flexible integration into broadcast and video production systems.
The converter supports SD, HD, Ultra HD, and 4K DCI video standards, including 2160p rates up to 60 fps and 4K DCI formats including 4Kp24, 4Kp47.95, and 4Kp48. SDI rates include 270Mb, 1.5G, 3G, 6G, and 12G, with automatic detection of SD, HD, 2K, Ultra HD, and 4K formats. SDI compliance includes SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1, SMPTE 2082-10, SMPTE 2084, and SMPTE 2108-1.
The Micro Converter HDMI to SDI 12G features 4:2:2 color precision and YUV color space. A 33-point LUT can be loaded through the software utility for calibrating or improving monitor color. Reclocking helps maintain SDI signal integrity, while USB Type-C provides configuration, software upgrades, and power.
The converter supports Mac 10.15 Catalina, Mac 11.1 Big Sur or later, and Windows 10 64-bit. Power consumption is 4W max., with an operational voltage range of 4.4V to 5.25V DC. Its compact design makes it suitable for mobile production, camera, broadcast, and monitoring applications.
For professional HDMI-to-12G-SDI conversion with Ultra HD and 4K DCI support, Micro Converter HDMI to SDI 12G provides high-bandwidth connectivity in a compact format. Get Fast Delivery in Doha, Al Wakrah, Al Rayyan.
