The Blackmagic Camera Fiber Converter lets you extend and power your URSA Broadcast from up to 2 km away using industry standard SMPTE fiber cables. It also includes common live camera controls with multiple channels of talkback and standard television industry talkback headset connections. The converter features 1 Ultra HD camera feed, plus 3 HD return feeds in a compact IP video based design.
Designed for professional broadcast workflows, the Blackmagic Camera Fiber Converter in Global provides SMPTE hybrid fiber connectivity, 12G SDI camera input and multiple 3G SDI return outputs. Two 5-pin XLR connections support headset talkback with three-way audio mixing, while two 3-pin XLR inputs support AES, line or microphone input with phantom power. A USB-C connector is also included for computer connectivity.
The converter supports HD formats including 720p and 1080p standards, alongside Ultra HD formats up to 2160p60. It provides 4:2:2 video sampling, 10-bit color precision and Rec.709 and Rec.2020 color spaces. Multiple SDI rate support allows switching between HD, 3G-SDI, 6G-SDI and 12G-SDI for flexible professional video connections.
With operating temperatures from 0°C to 40°C and relative humidity from 0% to 90% non-condensing, it is suited to demanding production environments. The package includes a mounting bracket, screws, three short 12G SDI cables and a software download wallet. Fast Delivery in makes it a practical choice for broadcast and live production setups.
