The ATEM Micro Camera Panel is a portable camera panel featuring high-end broadcast CCU controls for professional multi-camera production. It allows operators to control iris, pedestal, shutter, white balance, master gain, RGB balance and more for up to 8 cameras from a single panel. The panel connects to ATEM Software Control through Bluetooth or USB-C, providing flexible operation in studio and portable production environments.
For camera control workflows in Global, the panel provides eight NKK camera selection buttons that can be assigned through the setup utility. Camera numbers use green for off-air and red for on-air status. A three-axis joystick, preview button, auto iris control, coarse iris control and dedicated setup functions provide precise camera adjustment. The iris range is CLS f32 to f1.2, while gain ranges from -12dB to +32dB. ND filter settings include 0, 2, 4 and 6.
The ATEM Micro Camera Panel also provides shutter control from 1/24 to 1/2000 and white balance adjustment from 2500K to 10,000K. Operators can recall up to five scenes per camera, while the Panel Active function helps protect settings during operation. It supports Mac 14.0 Sonoma, Mac 15.0 Sequoia or later, Windows 10 and 11, and Windows 11 for ARM.
Powered by an internal battery, the panel provides a minimum three-hour battery life under normal use and consumes up to 4W. USB-C supports external power, battery charging and firmware updates. The ATEM Micro Camera Panel is suitable for professional camera control across production environments in and includes a one-year limited manufacturer's warranty.
